| Assignment of the control device | Electrically operated control device |
| Design of the control device | Flush-mounted built-in control device |
| Automatic action type of the control device | Action type 1 (electronic disconnection) |
| Number of switchings | Min 200,000 |
| Power supply voltage | 230 V~, 50 Hz |
| Rated pulse voltage | 2,500 V~ |
| (Overvoltage category II for single-phase system) |
| Voltage protection | For 230 V~ grids: |
| Maximum — 253 V~ |
| Minimum — 184 V~ |
|
| We recommend disabling this protection if WallSwitch is connected to 110 V~ grids. |
| Maximum load current | 10 А |
| Maximum current protection | Available, 13 A |
| Output power (resistive load 230 V~) | Up to 2.3 kW |
| Output power (resistive load 230 V~) | Up to 3 kW |
| Operating mode | Pulse or bistable (firmware version 5.54.1.0 and higher. Production date from March 5, 2020) |
|
| Bistable only (firmware version under 5.54.1.0) |
|
| How to check the manufacture date of a detector or device |
| Pulse duration | 1 to 255 s (firmware version 5.54.1.0 and higher) |
| Energy consumption monitoring | Available are: current, voltage, power consumption, electrical energy meter |
| Energy consumption of the device in standby mode | Less than 1 W |
| Radio communication protocol | Jeweller |
|
| Learn more |
| Radio frequency band | 866.0 – 866.5 MHz |
| 868.0 – 868.6 MHz |
| 868.7 – 869.2 MHz |
| 905.0 – 926.5 MHz |
| 915.85 – 926.5 MHz |
| 921.0 – 922.0 MHz |
|
| Depends on the sales region. |
| Compatibility | All Ajax hubs, and radio signal range extenders |
| Radio signal modulation | GFSK |
| Radio signal range | Up to 1,000 m |
| in an open space |
|
| Learn more |
| Pollution degree | 2 |
| for indoor use only |
| Protection class | IP20 |
| Operating temperature range | From 0°С to +64°С |
| Maximum temperature protection | Available, +65°C |
| Operating humidity | Up to 75% |
| Dimensions | 39 × 33 × 18 mm |
| Weight | 30 g |
| Service life | 10 years |
|
|
