| Voltage (Operating): | 9 VDC to 15 VDC |
| Current (Maximum): | < 25 mA |
| Current (Standby): | 13 mA |
| Relay: | Solid state relay, normally-closed (NC) contacts power supervised. 3 W, 125 mA, 25 VDC, resistance < 10 Ω. |
| Tamper: | Normally-closed (NC) contacts (with cover on) rated at 25 VDC, 125 mA maximum. Connect tamper circuit to 24-hour protection circuit. |
| Trouble: | Solid‑state relay normally-closed (NC) contacts. |
| Color: | White |
| Dimensions: | 136 mm x 69 mm x 58 mm (5.25 in. x 2.75 in. x 2.25 in.) |
| Material: | High-impact ABS plastic |
| Alarm Indicator: | Blue LED for TriTech alarms |
| Zones: | 86 |
| Radio Frequency Interference (RFI) immunity: | No alarm or setup on critical frequencies in the range from 26 MHz to 1 GHz at 50 V/m. |
| Relative Humidity: | 0 to 95%, non-condensing |
| Temperature (Operating and Storage): | -29°C to +55°C (-20°F to +130°F) For UL Certificated installations, 0°C to +49°C (+32°F to +120°F) |
| Protection Rating: | IP41, IK04 (EN 60529, EN 50102) |
-
