PoE+ Midspan

  • Supports IEEE802.3af, IEEE802.3at standard
  • Conform IEEE802.3, IEEE802.3u and IEEE802.3ab standards
  • Wide temperature design: ﹣10°C~55°C

Technical Specification

Model

TAM1GT1GT-30

Ethernet Port

1*10/100/1000 Base-T

1*10/100/1000 Base-T( PoE power supply)

PoE Power Consumption

Power output≤30W

PoE Protocol

IEEE802.3af, IEEE802.3at

LED Indicator

PSE: Indicates the device is delivering power to the PD.(Green)

PWR: Indicates the device is working properly. (Green)

Application Humidity

10%~90%

Power

AC100~240V 50/60Hz

Working Temperature

-10°C~55°C

Weight

250g

Dimension(W×D×H)

132.3mm×60mm×33mm
